426351/A

cNODEMicro31-180

Thetransponderunitconsistofhousing,transducer,internalbatteryandelectronics.The

unitisequippedwithanexternalconnectorforchargingandconguration.

Batterycharger

ItchargestheinternalTransponderbatteryinapproximately1hour.TheLEDcharge

statusindicatorshowswhenchargingiscomplete.

TTC30(TransponderTestandConguration

unit)

TheTTC30unitisforondecktestingandcongurationofthemediumfrequency

Transponders.TheTTC30cantestallKONGSBERGTransponderchannels,Cymbal

andHPR400.ItcanalsotesttelemetryTransponderswithinternalandexternalsensors.

Testandcongurationcable(TTCtoMicro)

ThiscableconnectstheMicrototheTTC(Transpondertestandconguration)unit.

Mainsystemunits
