28

426351/A

Externalconnector

Theexternalconnectorisforconguration,responder,on/offfunctionandcharging.

Faceview(male):

Pin1,2and3isforconguration.

Pin4and5isforresponderfunction.

Pin6isforon/offfunction.

Pin7and8isforexternalpower.

PinnumberSignal

1TXRS–232

2GND

3RXRS–232

4RESPONDERTRIGGER+

5

RESPONDERTRIGGER–

6

ON/OFF

7

EXTERNALPOWER(24V)

8GND

cNODEMicroInstructionManual
