426351/A

•thebatterymightbefaulty.Contactyourlocal

KongsbergMaritimeofceifthisisthecase.

NolightItnormallytakesabout

30secondsbeforethe

batterystartscharging

andtheLEDindicator

startsashinggreenafter

connectingthecNODE

batterychargertothe

cNODEMicroandthen

tothemains(110or220

Vac).

IfthereisstillnochangetotheLEDindicatorafter1

minutethendothefollowing:

•disconnectallcablesandwait1minutebefore

reconnectingthecablesandconnectpowersupplyto

mains(110or220V ac).

IftheLEDindicatorisstillnolightthenthefollowing

mighthaveoccurred:

•thechargerorcNODEMicromightbefaulty.

ContactyourlocalKongsbergMaritimeofceifthis

isthecase.

cNODEMicroInstructionManual
