Kongsberg SIMRAD CP40 - Waypoint Navigation

CP40/50 NAV menus & navigation examples Chapter 6
73
6.5.2 Waypoint navigation
There are two ways of activating Waypoint navigation:
1. With cursor placed on destination waypoint
CHART
Shortcut to chart 1 display
Press the cursor key to activate the cursor, then move the cursor to
your destination waypoint
GOTO
Select NAV mode, and…
2
Select Waypoint
A course line will now be drawn from ship’s position to destination
waypoint.
2. Activate Waypoint navigation via menu
MENU
Call up the menu bar, and…
4,2
select “WP” in Navigation menu
This will activate the pop-up window “Navigate to WP” from where
you can choose which waypoint you wish to sail to:
Use the cursor to scroll up/down in the waypoint list, or place cursor
on the WP number, and…
+/-
Scroll up/down with +/- keys, or…
0-9
Key in the number of the waypoint you wish to sail to
ENT
Start navigation
A course line will now be drawn from ship’s position to destination
waypoint.
