Kongsberg SIMRAD CP40 - 8.2 Installation of CP50 DGPS Chartplotter

CP40/50 Installation and service Chapter 8
97
74 (2.9)
116 (4.6)
376 (14.8)
419 (16.5)
445 (17.5)
8.2 Installation of CP50 DGPS Chartplotter
The CP50 can be flat or bracket mounted – overhead*, bulkhead* or console.
Console mounting
* Overhead and bulkhead
mounting is only possible if
using a distance piece.
20 (0.8)
196 (7.7)
75 (3.0)
