3.3.9 PLOT function
The CP40/50 Chartplotter is designed to make navigation easy and
safe. Making routes, drawing lines and plotting waypoints, etc. are all
done directly on the chart. Very straightforward and uncomplicated.
The PLOT function is available from various displays as indicated
below.
PLOT
With chart in active display, press [PLOT] to call up an INFO
window with the following to choose from:
PLOT new data
1
Plot waypoint
2
Plot waypoint with name etc.
3
Plot ship’s position as waypoint
4
Make route
5
Draw line
6
Plot cursor position as target
MENU
Exit
1
From active chart display with cursor ON:
Plot and save cursor position as a waypoint.
2
From active chart display with cursor ON:
Plot and save cursor position as a waypoint, insert a location name
(cf.section 2.6), adjust the position by keying in new figures, change
the symbol (cf.section 2.5), or change color on the symbol.
3
From any display:
Plot and save ship’s position as a waypoint including actual depth;
insert a location name (cf.section 2.6), change the symbol (cf.section
2.5), adjust the depth, and change the color.
4
From active chart display with cursor ON:
You can quickly make a route by plotting cursor’s position, one after
another i.e. place the cursor on the first position of the route you wish
to make, and press [PLOT]. Move cursor to next position, and press
