CP40/50 NAV menus & navigation examples Chapter 6
75
to answer a couple of questions:
Direction in route: FORWARD / REVERSE
Navigation from your position: YES / NO
etc.
ENT
When ready, press [ENT] to Start navigation
It is possible to mix and match the data you require to have on the
screen e.g. ½ window for the chart display, ¼ window for the
navigation display, and ¼ window for the Set & drift trim display or
ETA & AVN display, maybe. The choice is yours. Refer to section 2.1
Fundamentals of the PAGE and WINdow system.
GOTO
Pressing [GOTO] from chart display during navigation will activate an
INFO window with the following functions to choose from:
1. Advance (to next waypoint in route)
2. Restart to approaching point (in case you have drifted off course)
3. Turn NAV OFF.
MENU
Pressing [MENU] and [4] from an active data display during navigation
4
will give access to the following displays / feature:
1. Navigation display
2. Turn NAV off
3. ETA & AVN
4. Set & drift trim
5. WP advance
2. Activate Route navigation via menu
MENU
Call up the menu bar, and…
4,3
select “ROUTE” in Navigation menu
This will activate the pop-up window “Navigate in route” from where
you can choose which route you wish to select for navigation:
