Troubleshooting
4
C550
4-35
Clearing a paper misfeed in
the automatic duplex
unit
!
Detail
For details on the positions of paper
misfeeds, refer to
“Paper misfeed in-
dications” on page
4-6.
1
Open the door of the au-
tomatic duplex unit.
2
Slowly remove any mis-
fed paper from the auto-
matic dupl
ex unit.
306
308
