Utility mode
11
C550 11-93
10 Check the print result.
– Check that the folding positions were adjusted.
– If more adjustment is necessary, repeat steps 6 through 9.
Cover Sheet Feeder Size Adjustment
The sensors for detecting the size of paper loaded in the paper trays of the
optional post inserter can be adjusted.
2
Note
[Cover Sheet Feeder Size Adjustment] appears only if optional post in-
serter is installed.
1 Display the Administrator Setting screen.
– For details on displaying the Administrator Settings screen, refer to
“Displaying the Administrator Settings screen” on page 11-51.
2 Touch [1 System Settings].
The System Settings screen appears.
3 Touch [7 Expert Adjustment].
The Expert Adjustment screen appears.
4 Touch [3 Finisher Adjustment].
The Finisher Adjustment screen appears.
5 Touch [Forward→], and then touch [4 Cover Sheet Feeder Size Adjust-
ment].
The Cover Sheet Tray Size Adjustment screen appears.
To Next Page
