Kontron KTH81/mITX - Page 24

KTD-N0882-I Page 24 System Specification
KTQ87/KTH81 Users Guide
mITX, Low Power Configuration results
DOS Idle, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
+12V
96
1.158
+12V P4
1359
16.390
+5V
638
3.228
+3V3
491
1.664
-12V
21
0.236
5VSB
17
0.087
Total
22.8
Windows 7, mean
3DMARK2006 ( first scene ) + Burnin Test
Supply
Current draw
[mA]
Power consumption
[W]
+12V
102
1.230
+12V P4
2420
29.185
+5V
1167
5.905
+3V3
494
1.675
-12V
22
0.247
5VSB
20
0.102
Total
38.3
S3 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
418
2.140
Total
2.1
S4 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
267
1.367
Total
1.4
S5 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
267
1.367
Total
1.4
