mITX, High Power Configuration results
DOS Idle, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
+12V
695
8.381
+12V P4
1820
21.949
+5V
902
4.564
+3V3
578
1.959
-12V
22
0.247
5VSB
20
0.102
Total
37.2
Windows 7, mean
3DMARK2006 ( first scene ) +Burnin test
Supply
Current draw
[mA]
Power consumption
[W]
+12V
3320
40.039
+12V P4
3310
39.919
+5V
1145
5.794
+3V3
1121
3.800
-12V
18
0.202
5VSB
15
0.077
Total
89.8
S3 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
429
2.196
Total
2.2
S4 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
273
1.398
Total
1.4
S5 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
269
1.377
Total
1.4
