KTD-N0882-I Page 27 System Specification
KTQ87/KTH81 Users Guide
Flex, Low Power Configuration results
DOS Idle, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
+12V
91
1.092
+12V P4
970
11.640
+5V
997
4.985
+3V3
739
2.439
-12V
11
0.132
5VSB
5
0.025
Total
20.3
Windows 7, mean
3DMARK2006 ( first scene ) +Burnin test
Supply
Current draw
[mA]
Power consumption
[W]
+12V
101
1.212
+12V P4
2048
24.576
+5V
2027
10.135
+3V3
843
2.782
-12V
0
0
5VSB
8
0.040
Total
38.7
S3 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
286
1.43
Total
1.4
S4 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
130
0.715
Total
0.7
S5 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
123
0.677
Total
0.7
