KTD-N0882-I Page 28 System Specification
KTQ87/KTH81 Users Guide
Flex, Medium Power Configuration results
DOS Idle, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
+12V
154
1.848
+12V P4
1363
16.356
+5V
1083
5.415
+3V3
856
2.825
-12V
11
0.132
5VSB
8
0.040
Total
26.6
Windows 7, mean
3DMARK2006 ( first scene ) +Burnin test
Supply
Current draw
[mA]
Power consumption
[W]
+12V
0 TBD
0 TBD
+12V P4
4100 TBD
49.200 TBD
+5V
2932
14.660
+3V3
867
2.861
-12V
0
0
5VSB
17
0.085
Total
66.8
S3 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
296
1.480
Total
1.5
S4 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
139
0.695
Total
0.7
S5 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
134
0.670
Total
0.7
