KTD-N0882-I Page 29 System Specification
KTQ87/KTH81 Users Guide
Flex, High Power Configuration results
DOS Idle, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
+12V
1285
15.420
+12V P4
1781
21.372
+5V
1175
5.875
+3V3
1530
5.049
-12V
12
0.144
5VSB
4
0.020
Total
47.9
Windows 7, mean
3DMARK2006 ( first scene ) +Burnin test
Supply
Current draw
[mA]
Power consumption
[W]
+12V
2790
33.480
+12V P4
2880
34.560
+5V
1896
9.480
+3V3
1665
5.495
-12V
12
0.144
5VSB
10
0.050
Total
83.2
S3 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
296
1.480
Total
1.5
S4 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
168
0.840
Total
0.8
S5 Mode, Mean, No external load
Supply
Current draw
[mA]
Power consumption
[W]
5VSB
134
0.670
Total
0.7
