Software
OS Support Windows Server, Linux
Mechanical
Dimension (L x W) Mini-ITX (170 mm x 170 mm / 6.70" x 6.70")
3.3. Environmental Conditions
The mITX-DNV is compliant with the following environmental conditions. It is the customer's responsibility to provide
sufficient airflow around each of the components to keep them within the allowed temperature range.
Table 2: Environmental Conditions
Operating Temperature 0 °C ~ 60 °C / 32 °F ~ 140 °F
Storage Temperature -20 °C ~ 80 °C / -4 °F ~ 176 °F
Humidity 0 % ~ 95 %
3.4. Standards and Certifications
The mITX-DNV meets the following standards and certification tests.
Table 3: Standards and Certifications
CE
 EN 55022: 2010 + AC: 2011 Class A
 EN 55024: 2010
 EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 Class D
 EN 61000-3-3: 2013
 EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013
 IEC 60950-1: 2005 (Second Edition) + Am 1: 2009 + Am 2: 2013
FCC
 FCC CFR Title 47 Part 15 Subpart B: 2014
 ANSI C63.4-2009
 ICES-003 Issue 5: 2012
 CISPR 22: 2008
 CAN/CSA-CISPR 22-10
3.5. Processor Support
The mITX-DNV is designed to support Intel® Denverton Processors, Atom™ C3000 Series. The BGA CPU is remounted
from factory. Kontron has defined the board versions as listed in the following table, so far all based on Embedded
CPUs. Other versions are expected at a later date.
Table 4: Processor Support
Name Core # Speed Turbo Embedded Cache Socket TDP Tj
Atom™ C3338 2 1.50 GHz 2.20 GHz Yes 4M FCBGA1310 9 W 100 °C
Atom™ C3538 4 2.10 GHz 2.10 GHz Yes 8M FCBGA1310 15 W 100 °C
