9.2.3. Power Setup Menu
The Power setup menu provides functions and a sub-screen for power configurations. The following sub-screen
function is included in the menu:
 WatchDog Timer Configuration
Figure 53: BIOS Power Setup Menu
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Power Configuration
Restore AC Power Loss [Power Off]
Power Saving Mode [Disabled]
Resume Event Control
→ ←: Select Screen
Resume By X553 1GbE-1 [Disabled]
↑ ↓: Select Item
Resume By X553 1GbE-2 [Disabled] Enter: Select
Resume By X553 1GbE-3 [Disabled] +/-: Change Opt.
Resume By X553 1GbE-4 [Disabled] F1: General Help
Resume By LAN I210-AT-1 [Disabled] F2: Previous Values
Resume By LAN I210-AT-2 [Disabled] F3: Optimized Defaults
Resume By RTC Alarm [Disabled] F4: Save & Exit
> WatchDog Timer Configuration ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
Restore AC Power
Loss
[Power Off], [Power
On], [Last State]
Control whether the system will stay on after AC power is
removed and then restored.
Select [Power Off] if you want the system to remain off after
power restored.
Select [Power On] if you use a power strip to turn the system on.
Power Saving Mode [Disabled], [EUP AUX
Power], [EUP SOC
Power]
Select whether to enable Power Saving Mode.
Resume By X553
1GbE-1/2/3/4
Resume By I210-AT-
1/2
[Disabled], [OS-
Driver], [FW-
MagicPacket]
Select whether to enable or disable Wake from LAN Device X553
NIC with Marvell 88E1543 Port 1/2/3/4 or Intel I210-AT Port 1/2
respectively.
Resume By RTC Alarm [Disabled], [Enabled] Select whether to enable or disable Wake Up on Alarm, to turn
on your system on a special day of the month.
