mITX-DNV - User Guide, Rev. 1.0
www.kontron.com
// 56
Jumper Position
Description
Pin 1-2 Pin 3-4 Pin 5-6
- - X +12V
“X” = Jumper set (short) and “-” = jumper not set (open)
