Korg minilogue User Manual

43
Button 3 (GLOBAL 3)
These parameters relate to the SYNC IN/SYNC OUT jack seings.
Sync In Unit [16th Note, 8th Note]
The Sync In Units determine how much the Sequencer will advance with each
pulse received via the SYNC IN jack.
16th Note: The Sequencer will advance one sixteenth note for each pulse.
8th Note: The Sequencer will advance one eighth note for each pulse.
TIP
When Step Resolution in the SEQ EDIT mode is set to 1/16, a sixteenth
note will be equal to one step, and an eighth note will be equal to two
steps.
Sync Out Unit [16th Note, 8th Note]
The Sync Out Units determine how far the Sequencer needs to advance in or-
der to generate a pulse via the SYNC OUT jack.
16th Note: A pulse will be outpued for every sixteenth note.
8th Note: A pulse will be outpued for every eighth note.
TIP
When Step Resolution in the SEQ EDIT mode is set to 1/16, a sixteenth
note will be equal to one step, and an eighth note will be equal to two
steps.
Sync In Polarity [Rise, Fall]
In order to achieve synchronization with other units, the polarity of the SYNC
IN jack may need to be changed.
Rise: The minilogue will sync to the pulse as it rises to its crest (the highest
point) of the waveform.
Fall: The minilogue will sync to the pulse as it falls to its trough (the lowest
point) of the waveform.
Sync Out Polarity [Rise, Fall]
In order for other units to correctly sync with the minilogue, the polarity of the
SYNC OUT jack may need to be changed.
Rise: The minilogue will create a sync pulse as it rises to its crest (the highest
point) of the waveform.
Fall: The minilogue will create a sync pulse as it falls to its trough (the lowest
point) of the waveform.

Korg minilogue Specifications

General

Product type	Analog synthesizer
Product color	Silver
User presets quantity	100
Keyboard number of keys	37
Maximum polyphony (notes)	4
Display type	OLED
Built-in display	Yes
Headphone outputs	1
DC input voltage	9 V
Power source type	AC

Weight and Dimensions

Depth	300 mm
Width	500 mm
Height	85 mm
Weight	2800 g
