Korg minilogue User Manual

44
Button 4 (GLOBAL 4)
These parameters relate to the minilogue’s MIDI capabilities.
MIDI Ch [1...16]
In order to communicate, the minilogue and your other MIDI devices must be
set to the same MIDI channel. This is both the Transmit and Receive channel.
Clock Source [Auto (USB), Auto (MIDI), Internal]
Many features of the minilogue can be sync’d to the tempo or BPM. This pa-
rameter allows you to specify whether the clock source is internal, or an exter-
nal MIDI Clock Source.
Auto (USB), Auto (MIDI): When there is no input, the internal clock will be
used; and when input is detected, the internal clock will be synchronized to the
clocks from the USB B and MIDI IN connectors respectively.
Internal: Only the internal clock to be used.
When a cable is plugged into the SYNC IN jack, the internal clock is
synchronized to the SYNC IN jack clock, regardless of the MIDI clock
seings.
Enable Rx MIDI [O, On]
Set this parameter to ON to allow the minilogue to receive MIDI messages.
Enable Tx MIDI [O, On]
Set this parameter to ON to allow the minilogue to transmit MIDI messages.
MIDI Route [USB+MIDI, USB]
MIDI signals can be sent and received via the MIDI and USB connectors, or by
the USB connector alone.
USB+MIDI: MIDI messages are received via the USB B connector and the MIDI
IN connector; messages are transmied from the USB B connector and the
MIDI OUT connector.
USB: MIDI messages will be transmied and received only via the USB B con-
nector. When using the USB connector as a MIDI interface, it is advantageous
to use this seing.

Korg minilogue Specifications

General

Product type	Analog synthesizer
Product color	Silver
User presets quantity	100
Keyboard number of keys	37
Maximum polyphony (notes)	4
Display type	OLED
Built-in display	Yes
Headphone outputs	1
DC input voltage	9 V
Power source type	AC

Weight and Dimensions

Depth	300 mm
Width	500 mm
Height	85 mm
Weight	2800 g
