Korg PA4X User Manual

38| Playing the Sounds
Select a Keyboard Set
1 To choose one of the available types of Keyboard Sets, touch the buttons
at the top of the window.
Type of Styles Meaning
Factory Standard Keyboard Sets, that cannot be modied.
User Locations where you can load new Keyboard Sets from an external
device, or save new or edited Keyboard Sets.
Direct User Keyboard Sets accessed directly from a storage device, without
rst having to load them.
2 In case you want to choose a different group of Keyboard Sets, either press
a different button in the KEYBOARD SET LIBRARY section, or touch one of
the tabs on the sides of the Keyboard Set Library Select window.
3 To choose one of the available pages in the selected Keyboard Set group, ei-
ther touch one of the P1…P6 tabs at the bottom of the window, or repeatedly

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
