Korg PA4X User Manual

40| Playing the Sounds
Choosing a Keyboard Set from a Style or a SongBook Entry
There are four matched Keyboard Sets in each Style or SongBook Entry,
fine-tuned for the containing Style or SongBook Entry. You can choose them
from the control panel or from the display.
Choose a Keyboard Set from the control panel
▪ Press one of the buttons in the KEYBOARD SET section.
Select a Keyboard Set from the display
1 While in the Main page, be sure the Kbd Set pane is selected. If it isn’t, touch
the Kbd Set tab to select it.
2 Touch one of the Keyboard Set names in the display to select it.
You will see the name of the selected Keyboard Set highlighted in the dedi-
cated area of the Main page. The Sounds assigned to the keyboard (shown in
the right half of the display) will change.
Digital Drawbars
You will notice that some Keyboard Sets in the Organ group of the library
contain the ‘DWB’ abbreviation in their name. These Keyboard Sets con-
tain Digital Drawbars Sounds, that are simulations of electro-mechanical
organs of the past.
When you choose one of them, the SLIDER MODE indicator goes to
DRAWBARS. Use the sliders to control the drawbars and the correspond-
ing footage of the organ sound.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
