Korg PA4X User Manual

48| Customizing the Sound sets
▪ To choose one of the available types of Sound, touch the buttons at the top
of the window.
Type of Sound Meaning
Factory Standard Sounds, that cannot be modied.
Legacy Standard Sounds allowing for greater compatibility with older Pa-
Series instruments. These Sounds may not sound as good as the
newer ones, but they will immediately work with older Styles or Songs.
GM/XG Standard Sounds, allowing for full compatibility with General MIDI
and XG Sounds and Drum Kits.
User Locations where you can load new Sounds and Drum Kits from an
external device, or save new or edited Sounds and Drum Kits.
▪ To choose a different group of Sounds, touch one of the tabs on the sides
of the window.
▪ To choose one of the available pages in the selected Sound group, touch one
of the P1…Px tabs at the bottom of the window.
2 Touch the name of the Sound you want to choose.
3 If you want to close the Sound Select window (and it does not close by itself),
press the EXIT button.
▪ Mixing the Keyboard Sounds
Adjusting the Sound’s volume
At its core, Pa4X is a mixer. As with any mixer, you can adjust the volume
level of each Sound, therefore changing the balance between the different
Sounds on the keyboard.
Adjust the Sound’s volume from the control panel
1 While in any page, be sure the lighted SLIDER MODE indicator is VOLUME.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
