Korg SGPROX User Manual

15
Playing the SGproX
LAYER / SPLIT switch
Each time you press the select switch, the Play mode will cycle between
〈SINGLE〉 (LED off) → 〈LAYER〉 (blinking) → 〈SPLIT〉 (lit) → 〈SINGLE〉.
This adjustment will return to the default setting when the power is turned off.
SINGLE: One program will sound when you play a note.
LAYER: Two programs will sound when you play a note.
SPLIT: Two different programs will sound for notes in the left
and right areas of the keyboard.
SINGLE: Press one program switch to choose the program. (The
switch LED will light.)
LAYER: Press one program switch to make the switch LED light, and the program shown in the upper line
of the LCD will change (referred to as the first program). Continuing to hold that switch, press
another select program switch to make the switch LED blink, and the program shown in the
lower line of the LCD will change (referred to as the second program).
If you wish to select programs that are in two different banks, or to modify the levels etc., use the following
procedure. Use the 〈CURSOR〉 switches to move through the various items that can be set, and the display
blinks. Use the 〈VALUE〉 switches and 〈VALUE〉 slider to
make settings.
1. Select the first program. (A01 to D16)
2. Use the 〈CURSOR〉 switches to move the cursor.
Specify the level of the first program (range of 0 to 127).
3. Use the 〈CURSOR〉 switches to move the cursor.
Select the second program (A01 to D16).
4. Use the 〈CURSOR〉 switches to move the cursor.
Specify the level of the second program (range of 0 to 127).
5. Use the 〈CURSOR〉 switches to move to the effect set-
ting display. Specify whether the second program will be
sent through effects 1 and 2, or only through effect 2.
The effect settings of the program selected as the first
program will be used, and the first program will be sent through both effects 1 and 2.
SPLIT: The way in which programs are selected and the settings for each item are the same as for LAYER.
The first program will be assigned to the right-
hand area (the high range).
1. Select the first program.
2. Use the 〈CURSOR〉 switches to move the cursor.
Specify the octave in which the first program will sound
(range of –2 to +2).
3. Use the 〈CURSOR〉 switches to move the cursor.
Select the second program.
4. Use the 〈CURSOR〉 switches to move the cursor.
Specify the octave in which the second program will
sound (range of –2 to +2).
5. Use the 〈CURSOR〉 switches to move the cursor.
Specify the split point (the bottom key of the area
in which the first program will sound) (range of C–1 to G9).
You can also set the split point by holding down the 〈PROGRAM〉 switch and pressing the desired note
on the keyboard.
6. Use the 〈CURSOR〉 switches to move to the effect setting display.
The settings and procedure here are the same as for LAYER.
First program
Second program
Second program
Split point (C4)
ProgramSingle
Layer
Split
First program
Level setting display
First program First program level
Second program
Second program level
Effect setting display
This display indicates that the second program will pass through
both effects 1 and 2.
Octave and Split point setting display
First program (right-hand area)
First program octave
Second program (left-hand area)
Second program octave
Split point
Effect setting display
This display indicates that the second program will pass through
only effect 2.
SINGLE
LAYER
SPLIT
