Controllers / MIDI
❍ Start, Stop, Clock [ F8, F8, F8..., FA, F8, F8, F8..., FC, F8, F8, F8... ]
This set differs from the others in the way in which the switch and slider will be used. (The Mode setting will be
ignored.)
Press the switch, and START [ FA ] will be transmitted. Press the switch again, and STOP [ FC ] will be transmitted.
The value specified as the SW value will transmitted as MIDI Clock [ F8 ] at the initial tempo (in the range of = 40
to 250), but you can use the slider to modify this while it is being transmitted.
Available types, ranges, initial values, and MIDI
transmit values (Internal)
Use with a controller O: available ×: unavailable
FIX: fixed value S(L): initial setting for controller lower limit value S(H): initial setting for controller upper limit value SW: initial SW setting W/L: AW1,2/AL1-4
Explanation of Internal control settings
• These settings are for controlling the internal tone generator. The TYPE name shown in the LCD will be
enclosed in [ ].
• Although these are for internal control, operating the assigned controller will also cause the correspond-
ing MIDI message to be transmitted.
• If [ FX Dyna Mod ] is selected, you will also need to specify (in the effect settings) that controller as the
modulation source ( p.50).
• These controls are not related to program parameters. Even if you use the sliders etc. to modify the
sound, the modified sound cannot be written.
• In the case of functions marked by asterisk (*), the values will be reset when program is changed in
Program mode.
VALUE CONTROLLER
TYPE RANGE FIX S(L) S(H) SW W/L AP AS MIDI (CC:Control Change)
[Volume] 0 to 127 127 00 127 32 O O O CC#07:Volume
[FX Dyna Mod]* 0 to 127 00 00 127 64 O O O CC#12:FX Control 1
[Sostenuto] OFF,ON OFF OFF ON ON O O O CC#66:Sostenuto
[Brightness]* –64 to +63 00 –64 +63 +63 O O O CC#74:Brightness
[Attack Time]* –64 to +63 00 –64 +63 –64 O O O CC#73:Attack Time
[Decay Time]* –64 to +63 00 –64 +63 –64 O O O CC#75: Deeay Time
[FX1 Depth]* 0 to 127 00 00 127 64 O O O CC#93:Eff 3 Depth
[FX2 Depth]* 0 to 127 00 00 127 64 O O O CC#91:Eff 1 Depth
[Pitch Bend] –8192 to +8191 00 –8192 +8191 +8191 O O O Pitch Bend
[LFO] 0 to 127 00 00 127 64 O O O CC#01:Modulation 1
