Korg SGPROX User Manual

51
Effects
0. No Effect
Select this when you do not wish to use an effect.
1. Reverb
This effect simulates the acoustics of a hall, giving the sound a natural acoustic ambiance. This provides the
reverberation of a mid-sized hall, and a natural feeling of space.
Parameters
Parameter name Range
Time Time over which the reverb will decay 0.2 to 9.9 sec
Hi Damp Attenuation of the high frequency range 0 to 99%
Pre Dly Time between direct sound and early reflections 0 to 200 ms
E.R Level of the early reflections 0 to 99
EQ Lo Cut/boost amount of the low frequency range –12 to +12 dB
EQ Hi Cut/boost amount of the high frequency range –12 to +12 dB
Effect Depth Effect balance DRY to FX
2. Early Reflection
Early reflections determine how the character of the acoustic space are isolated from the reverberation
effect.
A wide variety of effects can be produced by adjusting the early reflection time, such as adding thickness to
the sound, or adding an echo-like reflection.
Parameters
Parameter name Range
E.R Time Length of the early reflections (10 ms steps) 100 to 800 ms
Pre Delay
Time between the direct sound
and early reflections
0 to 200 ms
EQ Lo Cut/boost amount of the low frequency range –12 to +12 dB
EQ Hi Cut/boost amount of the high frequency range –12 to +12 dB
Effect Depth Effect balance DRY to FX
3. Stereo Delay
The stereo delay effect with feedback lets you specify an independent delay time for the left and right
channels. High Damp settings allow you to add a natural-sounding decay to the repeated sounds.
The equalizer (EQ Low, EQ High) settings will be valid even when Effect Depth is set to “DRY.”
Parameters
Parameter name Range
Time L Left channel delay time 0 to 500 ms
Time R Right channel delay time 0 to 500 ms
FB
Amount of feedback returned to the effect
(negative settings invert the phase)
–99 to +99%
Hi Damp Attenuation of the high frequency range 0 to 99%
EQ Lo Cut/boost amount of the low frequency range –12 to +12 dB
EQ Hi Cut/boost amount of the high frequency range –12 to +12 dB
Effect Depth Effect balance DRY to FX
EQ
Pre Delay Reverb
Dry Signal
Right
Left
Dry Signal
Mix
Mix
Dry
E.R Level
Time
Pre Delay
EQ
Pre Delay
Early Ref
Dry Signal
Right
Left
Dry Signal
Mix
Mix
Dry
E.R Time
Pre Delay
Delay L
Right
Left
Mix
Mix
Feedback
Feedback
Delay R
EQ
EQ
