53
Effects
7. Stereo Phaser
While a chorus or flanger creates an effect by modulating the delay time, a phaser modulates the phase of the input
signal. This creates a modulation or swelling effect that has a different character than either a chorus or flanger.
This is especially effective when applied to electric piano or bass sounds.
The maximum effect will be obtained when Effect Depth is set to 50:50.
Since the left channel and right channel are modulated in opposite phase, a spacious phasing effect is produced.
Parameters
Parameter name Range
Manual
Center frequency at which the phase shift
effect will apply
0 to 99
Mod Depth of phase shift modulation 0 to 99
Mod SP Modulation speed 0.03 to 30 Hz
FB
Amount of signal that is fed back into the effect
(negative values invert the phase)
–99 to +99%
LFO Select the modulation waveform SIN, TRI
Effect Depth Effect balance DRY to FX
8. Rotary Speaker
This effect simulates the sound of the rotary speakers that are often used with an electric organ.
Independent LFOs are used to simulate the rotation of the rotor and the horn. The controller selected for Src
can be used to switch the speed between fast and slow. When this occurs, the speed of rotation will change
at the rate specified by Acceleration, regardless of the speed at which the controller was moved.
Parameters
Parameter name Range
Src Select the control source NONE to Ctrl#12
Vibrato
Depth
Depth of the vibrato effect 0 to 15
Acceleration Time required to change speeds 0 to 15
SpeedSlow Speed of slow rotation 1 to 99
SpeedFast Speed of fast rotation 1 to 99
Effect Depth Effect balance DRY to FX
9. Auto Pan
This is a stereo effect that combines two tremolo blocks. Opposite-phase modulation is applied to each
tremolo block, causing the sound to be panned cyclically between left and right.
The equalizer (EQ Low, EQ High) settings will be valid even when Effect Depth is set to DRY.
Parameters
Parameter name Range
LFO Select the modulation waveform SIN, TRI
ModShape Adjust the modulation waveform –99 to +99%
Mod Modulation depth 0 to 99
Mod SP Modulation speed 0.03 to 30 Hz
EQ Lo Cut/boost amount of the low frequency range –12 to +12 dB
EQ Hi Cut/boost amount of the high frequency range –12 to +12 dB
Effect Depth Effect balance DRY to FX
Mod Wave Shape
Modulation
Level
99
0
+99
Phaser
Right
Left
Mix
Mix
MOD
Phaser
Dry Signal
Dry Signal
Rotary Speaker
Dry Signal
Right
Left
Dry Signal
Mix
Mix
Pan
Right
Left
Mix
Mix
MOD
Pan
EQ
EQ
