Effects
10. Wah
The controller selected for Src can be used to control the wah effect. If you specify Amp EG as the Src, an
auto-wah (touch-wah) effect will be produced.
Parameters
Parameter name Range
Src Select the control source
NONE to
Ctrl#12
I (Intensity) Mid-frequency sweep amount –15 to +15
Freq Center frequency of the filter 0 to 99
Peak Gain Peak gain of the filter band –12 to +12
Peak Width Filter bandwidth 00 to 99
Effect Depth Effect balance DRY to FX
11. Flanger-Delay
This applies a stereo delay to the output of a mono-in/stereo-out flanger which uses LFOs that are 90 degrees
out of phase. You can specify the feedback independently for the flanger and for the delay.
Parameters
Parameter name Range
Fln.DT Flanger delay time 0 to 50 ms
FB
Amount of feedback to the flanger
(negative values invert the phase)
–99 to +99%
Fln.Mod Modulation depth of the flanger 0 to 99
Mod SP Modulation speed of the flanger 1 to 99
Dly. DT Delay time 0 to 450 ms
FB
Amount of feedback to the delay
(negative values invert the phase)
–99 to +99%
Delay Level Delay level 0 to 99
Effect Depth Effect balance DRY to FX
12. Hyper Enhancer (available only for FX1)
This is a stereo enhancer. Unlike a conventional equalizer, this effect independently adds low frequency and
high frequency components as desired, producing a very clear sound with excellent presence.
Since this effect can increase the perceived loudness of the low range and emphasize the attacks, it is espe-
cially effective for piano.
When this effect is used, the page 7 〈FX1 DEPTH〉 value can be set only to “DRY” or “FX.”
For some sounds, increasing the “Lo Blend” and “Hi Blend” values may cause the output sound to be distorted. If
this occurs, adjust the “Tr im ” setting.
Parameters
Parameter name Range
Trim Input level 0 to 100
Lo Freq Cutoff frequency of the low range 1 to 70
Lo Blend Blend (boost) amount of the low range 0 to 100
Hi Freq Cutoff frequency of the high range 1 to 40
Hi Blend Blend (boost) amount of the high range 0 to 100
Effect Depth Effect switch DRY, FX
Wah
Right
Left
Mix
Mix
Source
Wah
Dry SignalDry Signal
Dry Signal
Delay L
Right
Left
Mix
Mix
Feedback
Feedback
Delay R
Flanger L
Feedback
Flanger R
Feedback
MOD
Dry Signal
Dry Signal
Delay Level
Delay Level
Enhancer
Dry Signal
Right
Left
Dry Signal
Enhancer
Sw
Sw
