59
Controllers / MIDI
VALUE CONTROLLER
TYPE RANGE FIX S(L) S(H) SW W/L AP AS MIDI ( n:Channel )
71:Harmonic Int 00 to 127 00 00 127 64 OOO[ Bn,47,vv ]
72:Release Time –64 to +63 00 –64 +63 –64 OOO[ Bn,48,vv ]
73:Attack Time –64 to +63 00 –64 +63 –64 OOO[ Bn,49,vv ]
74:Brightness –64 to +63 00 –64 +63 +63 OOO[ Bn,4A,vv ]
75:Decay Time 00 to 127 00 00 127 64 OOO[ Bn,4B,vv ]
76:Vibrato Rate 00 to 127 00 00 127 64 OOO[ Bn,4C,vv ]
77:Vibrato Depth 00 to 127 00 00 127 64 OOO[ Bn,4D,vv ]
78:Vibrato Delay 00 to 127 00 00 127 64 OOO[ Bn,4E,vv ]
00 to 127 00 00 127 64 OOO[ Bn,??,vv ]
84:Porta Ctrl C-1 to G9 C–1 C–1 G9 C4 OOO[ Bn,54,vv ]
00 to 127 00 00 127 64 OOO[ Bn,??,vv ]
91:Eff 1 Depth 00 to 127 00 00 127 64 OOO[ Bn,5B,vv ]
92:Eff 2 Depth 00 to 127 00 00 127 64 OOO[ Bn,5C,vv ]
93:Eff 3 Depth 00 to 127 00 00 127 64 OOO[ Bn,5D,vv ]
94:Eff 4 Depth 00 to 127 00 00 127 64 OOO[ Bn,5E,vv ]
95:Eff 5 Depth 00 to 127 00 00 127 64 OOO[ Bn,5F,vv ]
96:Increment ( Fixed ) O × O [ Bn,60,00 ]
97:Decrement ( Fixed ) O × O [ Bn,61,00 ]
98:NRPN(LSB) 00 to 127 00 00 02 01 O × O [ Bn,62,vv ]
99:NRPN(MSB) 00 to 127 00 00 02 01 O × O [ Bn,63,vv ]
100:RPN(LSB) 00 to 127 00 00 02 01 O × O [ Bn,64,vv ]
101:RPN(MSB) 00 to 127 00 00 00 00 O × O [ Bn,65,vv ]
00 to 127 00 00 127 64 O × O [ Bn,??,vv ]
120:A.Sound Off ( Fixed ) O × O [ Bn,78,00 ]
121:Reset A.Cntl ( Fixed ) O × O [ Bn,79,00 ]
122:Local Off/On OFF,ON ON OFF ON OFF O × O [ Bn,7A,vv ]
123:A.Notes Off ( Fixed ) O × O [ Bn,7B,00 ]
124:Omni Off ( Fixed ) O × O [ Bn,7C,00 ]
125:Omni On ( Fixed ) O × O [ Bn,7D,00 ]
126:Mono On 00 to 16 06 00 16 01 O × O [ Bn,7E,vv ]
127:Poly On ( Fixed ) O × O [ Bn,7F,00 ]
❋ Hexadecimal values are indicated by [ ]
● Explanation of MIDI transmission data (Individual)
When the selected controller is operated, the RANGE value is inserted at the vv portion of the MIDI column,
and the message will be transmitted.
Messages whose RANGE value is (Fixed) will be transmitted only when the switch is operated. (They will
not be transmitted by slider movements.)
❍ GM System On, GM System Off, Master Vol (Omni), Master Bal (Omni) are transmitted on channel = 127.
External MIDI devices will receive this message regardless of their receive channel.
❍ Concerning Song Posit (4/4)(3/4)
This message specifies the location at which a drum machine or sequencer will begin playback, in units of a measure.
With a setting of 4/4, you can specify the position in one-measure units for time signatures of 2/2, 4/4 or 8/8.
With a setting of 3/4, you can specify the position in one-measure units for time signatures of 3/4 or 6/8.
In either case, it is not possible to specify a position in greater detail than one measure.
If the song contains measures with different time signature before the specified location in the song, the location
will not be accurate.
❍ In the case of Start/Stop, Start [ FA ] and Stop [ FC ] messages will be transmitted alternately each time you press
that controller switch, regardless of the MODE setting.
If you also wish to transmit Clock [ F8 ] messages, set the function of another controller to Clock (Tapping).
❍ Clock (Tapping) will transmit MIDI Clock [ F8 ] messages at a tempo determined by the interval at which you press
that controller switch, regardless of the MODE setting.
Even while clock messages are being transmitted, you can press the switch twice to change the interval (tempo) at
which the clock messages are transmitted.
If the switch is pressed at an interval longer than 1.5 seconds (equivalent to = 40), this will be ignored and the
tempo will not change.
Conversely, if the interval is less than 0.2 seconds, this will be considered to be an interval of 0.2 seconds (equiva-
lent to = 300).
……
…
