22
Resampling an arpeggiated phrase in Pro-
gram mode
While performing in program or combination mode, and
using the arpeggiator if desired, you can resample your
performance as audio data (sound).
As an example, this section explains how to sample an
arpeggiated phrase in Program mode. Sampling can be
performed in the same way in Combination or
Sequencer modes as well.
1
Select the program that you want to resample.
Press the [PROG] key to enter Program mode.
Select program J028: Rezbo.
2
Turn the arpeggiator on (ARPEGGIATOR [ON/
OFF] key LED is lit), and play the keyboard to ver-
ify that a phrase is produced.
Make sure that the arpeggio tempo “” is set to 120.
3
Press the Sampling tab to access the P0: Play, Sam-
pling page.
4
Press the menu button, and select “Auto Sampling
Setup.”
The dialog box will appear.
5
Choose “Resample Program Play.”
This will make the appropriate settings for resam-
pling your performance on a program.
6
Make the following settings for Resample Pro-
gram Play.
Set “Save to” to RAM. The resampled data will be
written to sample memory (RAM).
Check “Convert to Program.” After resampling, the
data will automatically be converted a program with
the number you specify in “Program.”
Use “Program” to specify the save-destination of the
sample created by resampling. You’ll probably want
to use bank E.
7
Press the OK button to execute the command.
Settings for resampling are now completed.
Take a minute to verify that these are the settings that
have been made.
Input 1 “BUS (IFX/Indiv.) Select”: Off
Input 2 “BUS (IFX/Indiv.) Select”: Off
The sound from the INPUT 1, 2 jacks will not be
input.
“Source BUS”: L/R
The sound sent to the L/R bus will be sampled.
VA LVE FORCE
VOLUME VALUE
PROGCOMBI
SAMPLINGSEQ
GLOBALS.PLAY
COMPAREMEDIA
A
B
INPUT TRIM
ASSIGNABLE 1
LPF CUTOFF
ULTRA BOOST
ASSIGNABLE 2
RESONANCE/HPF
TUBE GAIN
ASSIGNABLE 3
EG-INTENSITY
OUTPUT LEVEL
ASSIGNABLE 4
EG-RELEASE
ON/OFFREALTIME CONTROLS
1
2
2
2
1
1
3
8
3
Sampling
Tab
4
5
6
7
To Next Page
