2
VA LVE FORCE
VOLUME VALUE
PROGCOMBI
SAMPLINGSEQ
GLOBALS.PLAY
COMPAREMEDIA
A
B
INPUT TRIM
ASSIGNABLE 1
LPF CUTOFF
ULTRA BOOST
ASSIGNABLE 2
RESONANCE/HPF
TUBE GAIN
ASSIGNABLE 3
EG-INTENSITY
OUTPUT LEVEL
ASSIGNABLE 4
EG-RELEASE
ON/OFFREALTIME CONTROLS
21
2
1
1
7
6
Basic
Tab
Listening to the demo songs
Loading the demo song data
Let’s start by listening to the TRITON Extreme’s demo
songs.
1
Press the [GLOBAL] key (it will light).
You’re in Global mode. Make sure that the Global
P0: Basic Setup page is displayed.
If this page is not displayed, press the [EXIT] key and
then the Basic tab.
2
Press the page menu button in the upper right
hand corner of the display.
3
Press “Load Preload/Demo Data.”
4
In the “Kind” field, choose “All (Preload PCG and
Demo Songs).”
When you execute loading, the preloaded data and
the demo song data will be loaded.
5
Press the OK button.
A dialog box will ask you for confirmation.
Press the
OK button
once again to load the data.
Never turn off the power while data is being loaded.
If the Memory Protected dialog appears, press the Sys-
tem Pref. tab and clear the check mark from the mem-
ory protect setting. Then load the data again.
Selecting and playing a demo song
6
Press the [SEQ] key (it will light).
You’re in Sequencer mode. Make sure that the
Sequencer P0: Play/REC, Program T01–08 page is
selected. In this mode you can record songs and play
them back.
If this page is not displayed, press the [EXIT] key and
then the Prog.1–8 tab.
7
Select the demo song that you want to play.
Press “Song Select” to highlight it, and use the
[][] keys to select a song. Alternatively, you can
press the “Song Select” popup button and choose a
song from the popup menu.
8
Press the SEQUENCER [START/STOP] key.
The key will blink, and playback will begin.
To stop playback, press the [START/STOP] key once
again.
The demo song will not be retained when the power is
turned off, but you can load it again at any time.
3
4
5
7
Song Select
Prog. 1-8
Tab
Popup menu
To Next Page
Loading...
