KDS-8-MNGR – Using Embedded Web Pages
23
Streaming an Analog Audio Source to a Single Decoder
To route an analog audio source (on a detected encoder) to a display on an encoder:
1. In the Menu tabs, select Monitor & Control. The Video page appears.
2. Click Analog Audio. The Analog Audio page appears.
Figure 15: Monitor & Control Tab – Analog Audio Page
3. Click and drag a source button in the transmitter area to the preferred display in the
receiver area.
4. Release the mouse button.
The routed source name appears below the display name.
The selected source and routed displays change their color.
You can also drag and drop display decoders to an encoder source on the transmitter side to
activate a new streaming route.
The source on the encoder is streamed to the decoder.
Streaming an Analog Audio Source to Multiple Decoders
To route an analog audio source (on a detected encoder) to multiple encoders:
1. In the Menu tabs, select Monitor & Control. The Video page appears.
2. Click Analog Audio. The HDMI Audio page appears.
3. Click and drag a source button in the transmitter area to a predefined HDMI audio group
or an All button in the receiver area.
4. Release the mouse button.
The routed source name appears below the group name.
The source on the encoder is streamed to multiple decoders.
