▪ Reboot all transmitters to reboot all detected transmitters.
▪ Reboot all receivers to reboot all detected receivers.
3. View the KDS-8-MNGR S/N (Serial Number).
System reset/reboot is complete.
Upgrading the Firmware
Use KDS-8-MNGR to remotely update the firmware
of this unit and the detected transmitters
and
receivers in the system. the Kit Plugin option is currently not available.
The update process can take several minutes to complete, especially if there are multiple
transmitters and receivers in the system.
Do not power off any units during the update process.
KDS-8-MNGR enables performing the following firmware upgrades:
• Upgrading KDS-8-MNGR Firmware on page 32.
• Upgrading Transmitter/Receiver Firmware on page 33.
Upgrading KDS-8-MNGR Firmware
To upgrade the KDS-8-MNGR firmware:
1. In the Menu tabs, select System. The System page appears.
Figure 21: System Page
2. Under IP Master Controller (KDS-8-MNGR), click Choose file. The file selection window
opens.
3. Select the firmware update file (*.bin format) located on
your local PC.
4. Click Upgrade to begin the firmware update process. Once the firmware update process
has completed the unit reboots.
Firmware upgrade is complete.
