TP-590Rxr - Protocol 3000
71
10.2.4 Video/Audio Signal Changes
Number
Value
0
Video signal lost
1
New video signal detected
2
Audio signal lost
3
Audio signal detected
4
Disable 5V on video output if no input signal detected
5
Video cable unplugged
6
Audio cable unplugged
10.2.5 EDID Source
Number
Value
0
Input
1
Output
2
Default EDID
10.2.6 EDID Audio Capabilities
Number
Value
0
LPCM 2CH
1
LPCM 6CH
2
LPCM 8CH
3
Bitstream
4
HD
10.2.7 Layer Enumeration
Number
Value
1
Video
2
Audio
3
Data
4
IR
5
USB
10.2.8 Signal Validation
Number
Value
0
Signal or sink is not valid
1
Signal or sink is valid
2
Sink and EDID is valid
