3 Overview
The TP-590Rxr HDMI Line Receiver is a high-performance, extended range,
HDBaseT-technology receiver for HDMI, USB, audio, bidirectional RS-232, and IR
signals. The TP-590Rxr converts an HDBaseT signal back into HDMI, USB, audio,
RS-232, and IR signals.
The TP-590Rxr can be used together with a compatible transmitter to form an
extended HDMI/data-line transmission and reception system.
The TP-590Rxr receiver features:
• A bandwidth of up to 10.2Gbps (3.4Gbps per graphic channel) in normal
mode; up to 4.95Gbps (1.65Gbps per graphic channel) in extended range
mode (in which the aggregate budget on the Auxiliary Channel is halved)
• System Range—Up to 130m (430ft) in normal mode and up to 180m (590ft)
in extended range mode (1080p @60Hz @24bpp) when using BC−HDKat6a
cables
For optimum range and performance, use Kramer's BC−HDKat6a or
equivalent cable. Note that the transmission range depends on the signal
resolution, source, and display used. The distance using non−Kramer
CAT 6 cable may not reach these ranges.
• Up to 4K UHD @60Hz (4:2:0) support in normal range mode
• Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K);
up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using
BC−HDKat6a cables
• HDTV compatibility and HDCP compliance
• Support for HDBaseT V2
• HDMI support - HDMI (deep color, x.v.Color™, lip sync, HDMI
uncompressed audio channels, Dolby TrueHD, DTS−HD, CEC, 2K, 4K, 3D)
• USB pass-through for connecting a peripheral device, such as, a mouse or a
keyboard
• Support for isochronous USB cameras
