KROHNE OPTIMASS 3000 - Heating Jacket; Purge Port Version

6 TECHNICAL DATA
38
OPTIMASS 3000
www.krohne.com 10/2015 - 4001593002 - MA OPTIMASS 3000 R02 en
6.5.5 Heating jacket / purge port version
Meter size 01 03 04
A [mm] / [inches] 129 ±5.0 / 5.01 ±0.2
B 45º (approximately)
C 45º ±6º
