1 SAFETY INSTRUCTIONS
6
OPTIMASS 3000
www.krohne.com 10/2015 - 4001593002 - MA OPTIMASS 3000 R02 en
1.4 Associated documents
This handbook should be read in conjunction with relevant documents in relation to:
• hazardous areas
• communications
• concentration
• corrosion
1.5 Pressure Equipment Directive (PED)
To ensure the PED integrity of the meter, you MUST check that the serial numbers on the
converter nameplate and the sensor nameplate are the same.
To comply with the requirements of the Pressure Equipment Directive (PED) the manufacturer
provides all the relevant technical data in the technical data section of this handbook. In addition
to which, the following should also be noted:
• Secondary pressure containment is supplied as standard.
• The PED / CRN approved secondary containment pressure is 30 barg / 435 psig at
20°C/68°F.
• The wiring feedthrough is made of Epoxy, PPS or PEEK with two O-rings made from FPM /
FKM & Hydrogenated Nitrile.
• If the measuring tube/s fails, the O-ring will be in contact with the process product.
• You MUST make sure that the O-ring material is suitable for the application.
• Alternative O-ring materials are available on request.
Secondary pressure containment
Secondary pressure containment is subject to de-rating according to temperature. Refer to the
de-rating graphs shown in the relevant section.
If a heating jacket is fitted, secondary pressure containment is limited to 10 barg / 145 psig at
20°C/68°F
LEGAL NOTICE!
The Pressure Equipment Directive places legal requirements on both the manufacturer and the
end user. Please read this section carefully!
Visual check
MA_OPTIMASS_3000_en_151014_4001593002_R02.book Page 6 Wednesday, October 14, 2015 1:20 PM
