Servicing the Timeclock

Series 4000 Badge Timeclock User’s Guide 4-11

Removing the Cover Assembly from the Timeclock

To remove the front cover, you must disconnect the timeclock from its power

source. For example, you may have to remove and replace the timeclock’s lithium

battery, or replace the timeclock itself.

1. Open the timeclock’s cover by using the security wrench to loosen the

security screw on the right side of the timeclock.

2. Disconnect the transformer in the timeclock from the AC power source.

Depending on how you installed the timeclock, do one of the following:

! Unplug the power cord from an AC outlet external to the timeclock.

! If the timeclock is mounted over an AC outlet, unplug the power cord

from that outlet.

! If you used the internal AC outlet, unplug the power cord from the

internal outlet.

Number Description

1 Security screw

2 Security wrench
