KSB CPK - 6 Interchangeability of Pump Components

CPK
9
Part No. Designation
161 Casing Cover 183 Support foot 210 Shaft 320
Angular contact ball brg. (set)
321.1/2 Deep groove ball bearing
322 Cylindrical Roller bearing 330 Bearing bracket 344 Bearing bracket lantern 433 Mechanical seal 452 Stuffing box gland 456 Stuffing box pressure ring 457 Neck ring 458 Lantern ring 461 Stuffing box packing 471 Seal cover 502 Wearing ring 507 Splash ring 524 Shaft Protection sleeve 648 Drip plate 922 Impeller nut
Pump
size
Bearing
bracket
32-125 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
32-160 2 2 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1
40-160 2 2 1 1 1 1 1 2 1 1 1 1 1 1 1 2 1 1 1 1
50-160 2 3 1 1 1 1 1 2 1 1 1 1 1 1 1 3 1 1 1 1
32-200 3 3 1 1 1 1 1 3 1 1 1 1 1 1 1 1 1 1 1 1
40-200 3 3 1 1 1 1 1 3 1 1 1 1 1 1 1 2 1 1 1 1
50-200 3 3 1 1 1 1 1 3 1 1 1 1 1 1 1 3 1 1 1 1
80-160 4 5 2 2 2 2 2 4 2 2 2 2 2 2 2 10 2 2 2 2
65-200 5 5 2 2 2 2 2 5 2 2 2 2 2 2 2 8 2 2 2 2
80-200 5 5 2 2 2 2 2 5 2 2 2 2 2 2 2 10 2 2 2 2
100-200 5 6 2 2 2 2 2 5 2 2 2 2 2 2 2 12 2 2 2 2
32-250 6 5 2 2 2 2 2 6 2 2 2 2 2 2 2 6 2 2 2 2
40-250 6 5 2 2 2 2 2 6 2 2 2 2 2 2 2 5 2 2 2 2
50-250 6 5 2 2 2 2 2 6 2 2 2 2 2 2 2 4 2 2 2 2
65-250 6 6 2 2 2 2 2 6 2 2 2 2 2 2 2 8 2 2 2 2
80-250 6 7 2 2 2 2 2 6 2 2 2 2 2 2 2 11 2 2 2 2
40-315 7 6 2 2 2 2 2 7 2 2 2 2 2 2 2 5 2 2 2 2
50-315 7 7 2 2 2 2 2 7 2 2 2 2 2 2 2 7 2 2 2 2
100-250 8 8 3 3 3 3 3 6 3 3 3 3 3 3 3 13 3 3 2 3
125-250 8 9 3 3 3 3 3 6 3 3 3 3 3 3 3 15 3 3 2 3
150-250 8 10 3 3 3 3 3 6 3 3 3 3 3 3 3 16 3 3 2 3
65-315 9 8 3 3 3 3 3 7 3 3 3 3 3 3 3 9 3 3 2 3
80-315 9 9 3 3 3 3 3 7 3 3 3 3 3 3 3 12 3 3 2 3
100-315 9 9 3 3 3 3 3 7 3 3 3 3 3 3 3 14 3 3 2 3
125-315 9 10 3 3 3 3 3 7 3 3 3 3 3 3 3 16 3 3 2 3
80-400 10 10 3 3 3 3 3 8 3 3 3 3 3 3 3 12 3 3 2 3
100-400 10 10 3 3 3 3 3 8 3 3 3 3 3 3 3 14 3 3 2 3
125-400 10 11 3 3 3 3 3 8 3 3 3 3 3 3 3 15 3 3 2 3
200-250 11 13 4 4 4 4 4 9 4 4 4 4 4 4 4 17 4 4 3 4
150-315 12 12 4 4 4 4 4 10 4 4 4 4 4 4 4 18 4 4 3 4
200-315 12 13 4 4 4 4 4 10 4 4 4 4 4 4 4 19 4 4 3 4
250-315 12 16 5 4 4 4 4 10 4 4 4 4 4 4 4 21 4 4 3 4
150-400 13 12 4 4 4 4 4 11 4 4 4 4 4 4 4 18 4 4 3 4
200-400 13 13 4 4 4 4 4 11 4 4 4 4 4 4 4 20 4 4 3 4
200-500 16 17 6 5 5 5 12 5 5 5 5 5 20 5 5 3 5
250-400 15 17 6 5 5 5 11 5 5 5 5 5 22 5 5 3 5
250-500 16 15 6 5 5 5 12 5 5 5 5 5 23 5 5 3 5
P25/62
P35/80
P45/120
P55/140
P65/160s
Note : Part nos. 102 impeller & 230 Volute casing respectively cannot be used in other pump sizes.
6 Interchangeability of pump components
