CPK
10
8.2 Cause-Remedy
1)
1. The pump delivers against an excessively high
discharge pressure
- open discharge valve further until the duty point
conditions have been attained (adjusted)
2. Excessively high back pressure
- fit an over size impeller
2)
- increase rotational speed
(applies to turbine or I.C. engine driven pumps)
3. The pump and/or piping are incompletely vented or
primed.
- vent or prime the pump and system completely.
4. Suction line or impeller clogged.
- Remove deposits in the pump and/or piping.
5. Formation of air pockets in piping.
- Alter piping layout
8. Faults
8.1 Faults, causes and suggested remedies.
Faults Code Number
Cause-remedy
Pump delivers insufficient 1,2,3,4,5,6,7,8,9,
liquid 10,11,18,28
Driver is overloaded 12,13,14,15,23,27,28
Excessively high pump 15
discharge pressure
Excessively high bearing 22,23,24,25,26
temperature
Leakage at the pump 29
Excessively leakage at 17,18,19,20,21,22,23,33
shaft seal
The pump runs rough 3,6,11,12,22,23,30,31,32
Excessive temperature 3,6,32
rise inside the pump
7 Recommended stock of spare parts for 2 years of operation
Part No. Designation Number of pumps (including stand by pumps)
2 3 4 5 6 8 10 and more
No. of spare parts
210 Shaft 1 1 2 2 2 3 30%
230 Impeller 1 1 2 2 2 3 30%
320 Angular contact ball bearings (set) 1 1 2 2 2 4 50%
321.01/02 Deep groov ball bearing 1 1 2 2 2 4 50%
322 Cylindrical roller bearing 1 1 2 2 3 4 30%
330 Bearing bracket - - - 1 1 1 2 per 10 nos.
433 Mechanical seal Refer works
454 Stuffing box pressure ring 1 1 2 2 2 3 30%
456 Neck ring 1 1 2 2 2 3 30%
458 Lantern ring 1 1 2 2 2 3 30%
461 Stuffing box packing (set) 2 2 3 3 3 4 40%
502 Casing wear ring 2 2 2 3 3 4 50%
503 Impeller Wear ring 2 2 2 3 3 4 50%
524 Shaft protection sleeve 2 2 2 3 3 4 50%
Gaskets (set) and O ring 4 6 8 8 9 12 150%
