KSB CTN - Noise Characteristics; Scope of Supply

4 Description of the Pump (Set)
18 of 76
CTN / CTN-H
several shaft sections. Above the soleplate, the shaft assembly is supported radially
and axially by thrust bearings (rolling element bearings) (5); below the soleplate, it is
only supported radially by plain bearings (2).
Sealing ▪ The pump is sealed with a shaft seal (either a standardised single or double
mechanical seal or a gland packing).
4.6 Noise characteristics
Table10: Surface sound pressure level L
pA
3)4)
Nominal
power
input P
N
Pump Pump set
2900 rpm 1450 rpm 960 rpm/
760rpm
2900 rpm 1450 rpm 960 rpm/
760rpm
[kW] [dB] [dB] [dB] [dB] [dB] [dB]
1,5 54 52 51 63 57 56
2,2 56 54 53 65 60 58
3 57 56 54 67 61 59
4 59 57 55 69 63 61
5,5 61 59 57 70 65 62
7,5 62 60 58 72 66 64
11 64 62 60 74 68 66
15 66 64 62 75 69 67
18,5 67 65 63 76 70 68
22 68 66 64 76 71 69
30 69 68 65 77 72 70
37 70 69 66 78 72 71
45 71 70 67 79 73 72
55 72 71 68 79 74 72
75 74 72 69 80 75 73
90 75 73 70 80 76 74
110 76 74 71 81 76 75
132 77 75 72 81 77 75
160 78 76 73 82 77 76
200 79 78 74 83 78 77
250 80 79 - 83 79 -
4.7 Scope of supply
Depending on the model, the following items are included in the scope of supply:
▪ Pump
Drive
▪ Surface-cooled IEC frame three-phase squirrel-cage motor
Coupling
▪ Flexible coupling
Soleplate
▪ Cast or plate material, flange dimensions to EN1092 or ASMEB16.3
Special accessories
▪ As required
3) Surface sound pressure level as per ISO3744 and EN12639 valid for pump operation in the Q/Qopt=0.8-1.1 range and for
non-cavitating operation.If noise levels are to be guaranteed: Add +3dB for measuring and constructional tolerance.
4) Increase for 60Hz operation: 3500rpm +3dB, 1750rpm +1dB, 1160rpm ±0dB
