6 Commissioning/Start-up/Shutdown
31 of 76
CTN / CTN-H
DANGER
Excessive surface temperature
Explosion hazard!
Risk of burns!
▷ Observe the permissible temperature classes. (ðSection2.9.2,Page11)
CAUTION
Lack of heating medium
Damage to the pump!
▷ Provide sufficient quantities of a suitable heating medium.
CAUTION
Time for warming up the pump too short
Damage to the pump!
▷ Check that the pump is sufficiently warmed up throughout.
CAUTION
Impermissibly high temperature of the heating medium
Fluid or heating medium could escape!
▷ Observe the application limits of the heating media.
Table14: Permissible pressure and temperature limits when using saturated vapour
Sizes Heating with saturated vapour, pipe assemblies made of:
St 1.4571
Pressure Temperature Pressure Temperature
[bar] [°C] [bar] [°C]
25/40/50 7.1 165 7.1 165
80/100
125/150
200/250
Table15: Permissible pressure and temperature limits when using superheated
vapour
Sizes Heating with superheated vapour, pipe assemblies made of:
St 1.4571
Pressure Temperature Pressure Temperature
[bar] [°C] [bar] [°C]
25/40/50 18.0 300 14.0 300
80/100 15.0 12.0
125/150 12.0 12.0
200/250 9.8 9.8
Flanged bend The flanged bend can also be heated as part of a special design.
