CTN / CTN-H
Part No. Description Scope of supply
321.02 Radial ball bearing
341 Drive lantern with coupling guard 681.05, screw 900.16, stud bolt 902.11, hexagon
nut 920.11
344 Bearing bracket lantern with bearing cover 360.02, gasket 400.34, joint ring 411.46, lip seal
421.02, studs 902.06, screwed plug 903.46, vent plug 913.01, socket
head cap screw 914.02, hexagon nut 920.06
350.04 Bearing housing with O-ring 412.10, bearing bush 545.03, grooved pin 561.22, grooved
pin 561.23, grub screw 904.12
421.02 Lip seal
451.02 Stuffing box housing with joint ring 411.33/.47, disc 550.01, stud 902.09, screwed plug
903.33/.34, hexagon nut 920.09
452.02 Gland follower
454.02 Stuffing box ring
458.02 Lantern ring
461.02 Gland packing
502.01/.02 Casing wear ring with grooved pin 561.01/.02, grub screw 904.03/.04
502.03/.04 Casing wear ring with grooved pin 561.07/.08, grub screw 904.34/0.35
524.02 Shaft protecting sleeve with O-ring 412.32, grub screw 904.14, parallel pin 562.06
525 Spacer sleeve
526.04 Centring sleeve with keywayed nut 920.24, lockwasher 931.03
529.01/.03 Bearing sleeve with grooved parallel pin 561.18/.19 or screw 900.18/.19 or grub screw
904.11/.12
529.02 Bearing sleeve
545.01 Bearing bush
545.02/.03 Bearing bush
638 Constant-level oiler
641 Oil level pipe with hexagon head bolt 901.94, gasket 400.21
71-9.01 Pipe assembly with gasket 400.18, hexagon head bolt 901.29, hexagon nut 920.29
71-9.02 Pipe assembly with gasket 400.17, hexagon head bolt 901.32, hexagon nut 920.32
72-1 Flanged bend with gasket 400.17
852.01 Threaded coupling
893.02 Soleplate with disc 550.17, eyebolt 900.03, studs 902.05/.12/.30/.31, hexagon nuts
920.05/.12/.30/.31
923 Bearing nut with socket head cap screw 914.12
