KSB PumpDrive - Page 127

Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-12-3-23 P_2
Data point H/P/Q
curve P_2 at
nominal speed
0 0 0 999 kW Customer
3-12-3-24 P_3
Data point H/P/Q
curve P_3 at
nominal speed
0 0 0 999 kW Customer
3-12-3-25 P_4
Data point H/P/Q
curve P_4 at
nominal speed
0 0 0 999 kW Customer
3-12-3-26 P_5
Data point H/P/Q
curve P_5 at
nominal speed
0 0 0 999 kW Customer
3-12-3-27 P_6
Data point H/P/Q
curve P_6 at
nominal speed
0 0 0 999 kW Customer
3-12-4 Pump Protection
Submenu
3-12-4-1 Q Lim High Flow
Maximum
permissible value for
Q
100 100 0 150 % Customer
3-12-4-2 Q Hi Timeout Tm
Time delay for
overload detection
20 20 0 120 s Customer
3-12-4-3 Q Hi Timeout Fn
Perform function
when overload
occurs
1 1 Customer No Function
Warning
Stop & Trip
3-12-4-4 Q Lim Low Flow
Limit value for
minimum flow stop
for Q
100 100 0 150 % Customer
3-12-4-5 Q Lo Timeout Tm
Time delay for low
flow detection
20 20 0 120 s Customer
3-12-4-6 Q Lo Timeout Fn
Perform function
when low flow
occurs
1 1 Customer No Function
Warning
Stop & Trip
3-12-4-7 Hyd Blk Factor
Limit value for
impeller blockage
85 85 0 100 % Customer
3-12-4-8 Hyd Blck Tmout
Time delay for
impeller blockage
10 10 0 1000 s Customer
3-12-4-9 Dry Run Factor
Limit value for dry
running
70 70 0 100 % Customer
3-12-4-10 Dry Run Timeout
Time delay for dry
running
5 5 0 1000 s Customer
3-12-4-11 Dry Run Enable
Enable/disable dry
running function
2 2 Customer Disabled
Enabled
3-12-5 Multipump Conf
Submenu
10 Parameter lists
PumpDrive
127 of 162
