Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-12-3-8 Q_1
Data point H/P/Q
curve Q_1 at
nominal speed
0 0 0 9999 m3/h Customer
3-12-3-9 Q_2
Data point H/P/Q
curve Q_2 at
nominal speed
0 0 0 9999 m3/h Customer
3-12-3-10 Q_3
Data point H/P/Q
curve Q_3 at
nominal speed
0 0 0 9999 m3/h Customer
3-12-3-11 Q_4
Data point H/P/Q
curve Q_4 at
nominal speed
0 0 0 9999 m3/h Customer
3-12-3-12 Q_5
Data point H/P/Q
curve Q_5 at
nominal speed
0 0 0 9999 m3/h Customer
3-12-3-13 Q_6
Data point H/P/Q
curve Q_6 at
nominal speed
0 0 0 9999 m3/h Customer
3-12-3-14 H_0
Data point H/P/Q
curve H_0 at
nominal speed
0 0 0 9999 m Customer
3-12-3-15 H_1
Data point H/P/Q
curve H_1 at
nominal speed
0 0 0 9999 m Customer
3-12-3-16 H_2
Data point H/P/Q
curve H_2 at
nominal speed
0 0 0 9999 m Customer
3-12-3-17 H_3
Data point H/P/Q
curve H_3 at
nominal speed
0 0 0 9999 m Customer
3-12-3-18 H_4
Data point H/P/Q
curve H_4 at
nominal speed
0 0 0 9999 m Customer
3-12-3-19 H_5
Data point H/P/Q
curve H_5 at
nominal speed
0 0 0 9999 m Customer
3-12-3-20 H_6
Data point H/P/Q
curve H_6 at
nominal speed
0 0 0 9999 m Customer
3-12-3-21 P_0
Data point H/P/Q
curve P_0 at
nominal speed
0 0 0 999 kW Customer
3-12-3-22 P_1
Data point H/P/Q
curve P_1 at
nominal speed
0 0 0 999 kW Customer
