Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-12-2-5 P % @ 60% fmax
Learning function:
Measured load P4 at
60 % of fmax
0 0 0 110 kW Customer
3-12-2-6 P % @ 70% fmax
Learning function:
Measured load P5 at
70 % of fmax
0 0 0 110 kW Customer
3-12-2-7 P % @ 80% fmax
Learning function:
Measured load P6 at
80 % of fmax
0 0 0 110 kW Customer
3-12-2-8 P % @ 90% fmax
Learning function:
Measured load P7 at
90 % of fmax
0 0 0 110 kW Customer
3-12-2-9 P % @ 100% fmax
Learning function:
Measured load at
100 % of fmax
0 0 0 110 kW Customer
3-12-2-10 learning time
Measurement
period for each
measuring point
30 30 30 500 s Customer
3-12-2-11 learn meas fail
Permissible
measuring error, in
percent, outside a
predefined
tolerance band
5 5 2 20 % Customer
3-12-3 Q/P/H Curves
Submenu for
displaying H/P/Q
curves
3-12-3-1 Rated p speed
Specification of
nominal pump
speed
0 0 0 9999 rpm Customer
3-12-3-2 RhoRho
Specification of
density of fluid
1000 1000 0 9999 kg/m3 Customer
3-12-3-3 No of Stages
Specification of
number of stages
1 1 0 100 Customer
3-12-3-4 Qopt
Specification of flow
rate at best
efficiency point
0 0 0 9999 m3/h Customer
3-12-3-5 Qmin
Specification of
minimum flow rate
0 0 0 9999 m3/h Customer
3-12-3-6 Qmax
Specification of
maximum flow rate
0 0 0 9999 m3/h Customer
3-12-3-7 Q_0
Data point H/P/Q
curve Q_0 at
nominal speed
0 0 0 9999 m3/h Customer
10 Parameter lists
