Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-11-3-1 Prop Const
Proportional gain of
current limitation
control
10 10 0 100 Factory -
3-11-3-2 Integral Const
Integral term of
current limitation
control
2 2 0 100 - Factory -
3-11-4 Max Output
Submenu for
specifying the
maximum output
values
- - - - - -
3-11-4-1 Max Out Freq
Assignment of
maximum output
frequency
50 50 25 70 Hz Customer -
3-11-4-2 Max Out Current
Assignment of
maximum output
current
0 0 0 500 A Customer -
3-11-5 PD Settings
Submenu for
PumpDrive settings
- - - - - - -
3-11-5-1 PDrive Size
PumpDrive power
class
3 3 1 16 - Customer -
3-11-5-2 Offset DC-Link
Offset DC link
voltage
350 350 200 365 V Factory -
3-12 Adv Pump Ctrl
Menu for Advanced Pump Control
3-12-1 Flow Rate Meas
Submenu for flow
rate (Q)
measurement
3-12-1-1 Flow Rate Meas
Q measurement/
estimation
1 1 Customer Measured
P/Q calculated
3-12-2 Low Q Limit
Submenu for
minimum flow rate
Q
3-12-2-1 Start Learn Prf
Start learning
function: Learn load
profile across
frequency range
1 1 Customer OFF
Start
3-12-2-2 P % @ 30% fmax
Learning function:
Measured load P1 at
30 % of fmax
0 0 0 110 kW Customer
3-12-2-3 P % @ 40% fmax
Learning function:
Measured load P2 at
40 % of fmax
0 0 0 110 kW Customer
3-12-2-4 P % @ 50% fmax
Learning function:
Measured load P3 at
50 % of fmax
0 0 0 110 kW Customer
