KSB PumpDrive - Page 123

Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-9-1-5 PI type
Process type of PI
controller
1 1 - - - Customer Constant Pressure
Variable Pressure
Constant Flow
Other Setpoint
3-9-1-6 PI Auto
Activate/deactivate
PI Auto mode
1 0 - - - Customer -
3-9-2 Feedbk Source
Submenu for selecting feedback (actual value) source
3-9-2-1 Feedbk Source
Selection of
feedback (actual
value) source
1 1 - - - Customer Analog IN 1
Analog IN 2
DIFF (AI1, AI2)
MIN (AI1, AI2)
MAX (AI1, AI2)
AVE (AI1, AI2)
Remote Actual
Value
3-10 Communication
Communication
menu
- - - - - - -
3-10-1 General Setting
Submenu for
general settings
- - - - - - -
3-10-1-1 Ctrl Guard Tm
Threshold value for
control word time
monitoring
4 4 2 10 s Customer -
3-10-1-2 Ctrl Wd Wrn Fnc
Perform function
upon control word
timeout
1 1 - - - Service -
3-10-1-3 Aux-main Grd Tm
Time at which
auxiliary main pump
takes over control
function
0.5 0.5 0.02 10 s Customer -
3-11 Add Settings
Menu for additional settings
3-11-1 Inverter Switch
Submenu for carrier
frequency
- - - - - - -
3-11-1-1 Switching Freq
Setting the carrier
frequency
bg bg - - - Service Selection list V
(⇨ Section 10.1
Page 129)
3-11-1-2 PWM Random
Activate/deactivate
random pulse width
modulation
6 6 - - - Service Selection list IV
(⇨ Section 10.1
Page 129)
3-11-2 Trip
Submenu
- - - - - - -
3-11-2-1 Trip Reset Mode
Trip reset mode
function
2 2 - - - Customer Manual Reset
10 s, 60 s, 5 m
Inf Reset @ 5 m
10 s, 60 s, 5 m, 1
Inf Reset @ 15 m
3-11-3 Crrnt Lim Ctrl
Submenu
- - - - - - -
-
10 Parameter lists
PumpDrive
123 of 162
