KSB PumpDrive - Page 122

Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-8-4-1 AO Source 1
Source 1 for Analog
OUT
8 8 - - - Customer No
Setpoint
Feedback
Nominal Powerr
Motor Voltage
Motor Current
Motor Speed
Output Frequency
DC Link Voltage
3-8-4-2 AO Source 2
Source 2 for Analog
OUT
1 1 - - - Customer No
Setpoint
Feedback
Nominal Powerr
Motor Voltage
Motor Current
Motor Speed
Output Frequency
DC Link Voltage
3-8-4-3 AO Source 3
Source 3 for Analog
OUT
1 1 - - - Customer No
Setpoint
Feedback
Nominal Powerr
Motor Voltage
Motor Current
Motor Speed
Output Frequency
DC Link Voltage
3-8-4-4 AO Source 4
Source 4 for Analog
OUT
1 1 - - - Customer No
Setpoint
Feedback
Nominal Powerr
Motor Voltage
Motor Current
Motor Speed
Output Frequency
DC Link Voltage
3-8-4-5 AO Lo Voltage
Analog OUT Voltage
too low
0 0 0 10 V Customer -
3-8-4-6 AO Hi Voltage
Analog OUT Voltage
too high
10 10 0.01 10 V Customer -
3-8-4-7 AO Time Const
Analog OUT Time
constant
0.5 0.5 0.01 1 s Customer -
3-9 PI-Controller
PI controller menu
3-9-1 Process PI Ctrl
Submenu
- - - - - - -
3-9-1-1 PI Mode
Disable/enable PI
controller
1 2 - - - Customer Disabled
Enabled
3-9-1-2 PI Prop Gain
PI controller
proportional gain
1 1 0 10 - Customer -
3-9-1-3 PI Integral Tm
PI controller integral
term
1 1 0 60 s Customer -
3-9-1-4 PI Sense
Control direction of
PI controller
0 0 - - - Customer -
10 Parameter lists
122 of 162
PumpDrive
