Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-8-2-7 Anlg IN 1 Lo
Low value for
Analog IN 1
0 0 0 3-8-2-8 3-8-2-6 Customer -
3-8-2-8 Anlg IN 1 Hi
High value for
Analog IN 2
100 100 3-8-2-7 9999 3-8-2-6 Customer -
3-8-2-9 AI1 Filter Tm
Analog IN 1 Filter
time constant
0.1 0.1 0.1 10 s Customer -
3-8-2-10 AI1 Scaling
Analog IN 1 Scaling
factor
1 1 0.5 2 Customer -
3-8-2-11 AI1 Descriptor
Setting of
parameters for
Analog IN 1
1 1 - - - Customer Process
Pressure P1
Pressure P2
Q
Temperature
3-8-3 Analog IN 2
Submenu, Analog IN
2 Low voltage
- - - - - - -
3-8-3-1 AI2 Setting
Selection of
measurement signal
at analog input
1 2 - - - Customer Current
Voltage
3-8-3-2 AI2 Lo Voltage
Analog IN 2 Low
current
0 0 0 3-8-3-3 V Customer -
3-8-3-3 AI2 Hi Voltage
Analog IN 2 High
current
10 10 3-8-3-2 10 V Customer -
3-8-3-4 AI2 Lo Current
Unit of Analog IN 2
4 4 0 3-8-3-5 mA Customer -
3-8-3-5 AI2 HI Current
Low value for
Analog IN 2
20 20 3-8-3-4 20 mA Customer -
3-8-3-6 AI2 Unit
High value for
Analog IN 2
1 1 - - - Customer Selection list III
(⇨ Section 10.1
Page 129)
3-8-3-7 Anlg IN 2 Lo
Analog IN 2 Filter
time constant
0 0 0 3-8-3-8 3-8-3-6 Customer -
3-8-3-8 Anlg IN 2 Hi
Analog IN 2 Scaling
factor
100 100 3-8-3-7 9999 3-8-3-6 Customer -
3-8-3-9 AI2 Filter Tm
Setting of
parameters for
Analog IN 1
0.1 0.1 0.1 10 s Customer -
3-8-3-10 AI2 Scaling
Analog IN 2 Scaling
factor
1 1 0.5 2 - Customer -
3-8-3-11 AI2 Descriptor
Setting of
parameters for
Analog IN 2
1 1 - - - Customer Process
Pressure P1
Pressure P2
Q
Temperature
3-8-4 Analog OUT 1
Submenu
- - - - - - -
10 Parameter lists
