Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-7-2-2 On Time Dly
Selection of time
delay between
event and response
1 1 0 360 s Customer -
3-7-2-3 Off Time Dly
Selection of time
delay between
event and response
1 1 0 360 s Customer -
3-7-3 Digital OUT 2
Submenu for display
of digital output 2
- - - - - - -
3-7-3-1 Dig OUT 2 Fnc
Selection of
function of digital
output 3
4 4 Customer Selection list II
(⇨ Section 10.1
Page 129)
3-7-3-2 On Time Dly
Selection of time
delay between
event and response
1 1 0 360 s Customer -
3-7-3-3 Off Time Dly
Selection of time
delay between
event and response
1 1 0 360 s Customer -
3-8 Analog IN/OUT
Menu for analog inputs and outputs
3-8-1 Analog IO Mode
Submenu
- - - - - - -
3-8-1-1 Live Zero TmDly
Time delay after live
zero detection
3 3 0.1 60 s Customer -
3-8-1-2 Live Zero Fnc
Live zero function
1 1 - - - Customer No Function
Stop
Min Motor Speed
Max Motor Speed
Freeze Output
Warning
Stop & Trip
3-8-2 Analog IN 1
Selection of
measurement signal
at analog input
- - - - - - -
3-8-2-1 AI1 Setting
AI 1 Setting
Selection of
measurement signal
at analog input
2 2 - - - Customer Current
Voltage
3-8-2-2 AI1 Lo Voltage
Analog IN 2 Low
voltage
0 0 0 3-8-2-3 V Customer -
3-8-2-3 AI1 Hi Voltage
Analog IN 1 High
voltage
10 10 3-8-2-2 10 V Customer -
3-8-2-4 AI1 Lo Current
Analog IN 1 Low
current
4 4 0 3-8-2-5 mA Customer -
3-8-2-5 AI1 Hi Current
Analog IN 1 High
current
20 20 3-8-2-4 20 mA Customer -
3-8-2-6 AI1 Unit
Unit of Analog IN 1
1 1 - - Customer Selection list III
(⇨ Section 10.1
Page 129)
10 Parameter lists
